Key Specifications:
| Property | Detail |
|---|---|
| Heating Zones | 7 Top / 7 Bottom (standard configuration) |
| Cooling Zones | 2 to 4 (depending on configuration) |
| Max Operating Temperature | 350°C (662°F) |
| Temperature Stability | ±0.5°C at set point |
| Heating Length | 213 cm (84 inches) |
| Board Width Capacity | Up to 53 cm (21 inches) |
| Conveyor Type | Edge grip or flat mesh belt |
| Conveyor Speed Range | 10-200 cm/min (4-78 inches/min) |
| Nitrogen Capability | Optional, for low oxygen (<100ppm typical) environments |
| Power Requirements | 480V, 3 Phase, 60/50 Hz (High Power) |
Key Features & Benefits:
-
Precise Thermal Control: Patented forced convection heating ensures even temperature across the board for flawless soldering.
-
High Throughput: Designed for continuous operation in demanding production environments.
-
Low Oxygen Soldering: Optional nitrogen system enables robust low-oxygen soldering processes.
-
Robust Construction: Built for 24/7 industrial operation with minimal maintenance and high reliability.
-
Advanced Software: User-friendly interface for easy recipe creation, storage, and process monitoring.
