Specifications
| Specifications | Model Parameters |
|---|---|
| Model | MF-H7 |
| Dimensions (LWH) | L1035mm W1300mm H1700mm |
| Weight of Equipment | 580KG |
| Transmission Motor Power | DC24V 69W * 2 |
| Air Source | 4-6kgf/cm² |
| Exhaust Volume Requirement | 6m³/min |
| Power Supply | AC220V 50/60HZ |
| Total Power | 1.8KW |
| Coating Stroke | X=450mm, Y=450mm, Z=100mm |
| Conveyor Rail Width | 50-450mm |
| PCB Component Height | Max 100mm (up and down) |
| PCB Board Edge Size | ≥5mm |
| Spraying Width | 3-20mm |
| Spraying Method | Atomizing + dispensing |
| Number of Program Storage | More than 1000 |
| Conveyor Rail | Special aluminum alloy track + stainless steel chain |
| Three-Axis Drive Mode | Servo motor + ball screw |
| Conveying Direction | L → R / R → L |
| Upper Layer Transmission Height | 920 ± 20mm |
| Guide Rail Adjustment | Software trigger control |
| Conveying Speed | 2-12m/min |
| Conveying Motor | Stepper motor |
| Lighting Part | Built-in lighting source |
| Detection Part | Built-in detection light source |
| Number of Glue Valves | 1 small atomizing valve + 1 dispensing valve |
